Small hole welded wire mesh fence for Anti climb security fence 358
fence
Specification of anti climb fencing
ANTI CLIMB FENCE is the ultimate heavy duty welded mesh panel providing the highest
degree of security with excellent see through visibility. It has
toe and finger proof profile. With spacing specification of 75mm x
12.5mm, it is impossible for fingers and toes to go through. Our
anti-climb fence is perfect as a guarded fence system because of
its exclusive thickness, anti-cutting materials and its framework
is very strong resistant and hard to uninstall. With our excellent
anti-climb fence supply, clients can enjoy the greatest relaxation
and secured protection from inside of your own.
| Panels | post |
| Fence | Panel Size | Post Size | Post Height | Total Number of Fixings |
| Height | Height/Width | Lenght/Width/Thickness | | Inters- 1 clemp | Corners-2 clamp |
| m | mm | mm | mm | | |
| 2.0 | 2007 x 2515 | 60x60x2.5mm | 2700 | 7 | 14 |
| 2.4 | 2400 x 2515 | 60x60x2.5mm | 3100 | 9 | 18 |
| 3.0 | 2400 x 2515 | 80x80x2.5mm | 3800 | 11 | 22 |
| 3.3 | 2997 x 2515 | 80x80x2.5mm | 4200 | 12 | 24 |
| 3.6 | 3302 x 2515 | 100x60x3mm | 4500 | 13 | 26 |
| 3.6 | 3607 x 2515 | 100x100x3mm | 4500 | 13 | 26 |
| 4.2 | 4204 x 2515 | 100x100x4mm | 5200 | 15 | 30 |
| 4.5 | 4496 x 2515 | 100x100x5mm | 5500 | 16 | 32 |
| 5.2 | 5207 x 2515 | 120x120x5mm | 6200 | 18 | 36 |
Application of anti climb fencing
With excellent see through visibility makes anti climb fencing is
very suitable to use on commercial, governmental and industrial
properties where you can enjoy both the ultimate security without
compromising the visibility of customers and others.And it is also
suitable for premium housing estate development, apartments and
condominium surroundings, schools,business parks, warehouses, power
plants, military sites, education facilities, hospitals and
residential areas.
Surface finish of anti climb fencing
1. Hot dipped galvanized
Hot-dip galvanizing is the process of dipping fabricated steel in a
bath of molten zinc to form a tightly-bonded alloy coating that provides superior
corrosion protection to steel.
2. Electro-galvanized and Powder coated
Electric galvanizing takes place before manufacture the product.
This generally results in a better appearance.
Powder coating is a dry finishing method in which electrically
charged particles of pigmented resins are sprayed onto a product, makes the product become colorful. We can do powder
coated based on RAL color card.
Production of anti climb fencing
