2.5mm Diameter Wire 3.6m Width Temporary Security Fencing With Chain Link

38MM Out Galvanized Pipe 6FT X 12FT Chain Link Temporary Fencing

Chain Link Temporary Fencing Introduction:

It is an alternative to its permanent counterpart when a fence is required on an interim basis when needed for storage, public safety or security, crowd control, or theft deterrence. It is also known as construction hoarding when used at construction sites. Other uses for temporary fencing include venue division at large events and public restriction on industrial construction sites. Temporary fencing is also often seen at special outdoor events, parking lots, and emergency/disaster relief sites. It offers the benefits of affordability and flexibility.

2.5mm Diameter Wire 3.6m Width Temporary Security Fencing With Chain Link

Chain Link Temporary Fencing drawing :

2.5mm Diameter Wire 3.6m Width Temporary Security Fencing With Chain Link

Chain Link Temporary Fencing size:

Chain Link Temporary Fence Specification
Material	Low carbon steel
Surface Treatment	Hot dipped galvanized
Fence height	4ft, 6ft, 8ft or customized size
Fence length	10ft, 12ft, 14ft, or customized size
Wire diameter	2.5mm, 2.7mm, 3mm, 3.5mm, 4mm, etc.
Frame tube	O.D. 32mm, 33.4mm, 42mm, etc
Cross brace tube	O.D. 25mm or 32mm, etc.
Base size	610x590mm, 762x460mm, etc
Chain link mesh size	50x50mm, 60x60mm, etc

Tubing	1¼"(32mm) 1⅜"(35mm) 1½"(38mm) 1⅗"(40mm) 1⅝"(42mm) 1⅞"(48mm)and so on
Thickness of Tubing	14ga/2.00mm 14.5ga/1.90mm 15ga/1.80mm 15.5ga/1.70mm 16ga /1.6mm 16.5ga/1.50mm 17ga1.42mm 18ga 1.22mm
Chain mesh aperture	2"x2"/(50mm x 50mm) 2¼"x2¼"(57mmx57mm) 2⅜"x2⅜"(60mmx60mm) 2½"x2½"(63mmx63mm)
Height	4ft/1220mm 6ft/1820mm 8ft/2420mm
Width	12ft /3650mm was wide acceptance by market also 8ft 9ft 10ft 14ft
Panels Size	6ft x 12ft ,8ft x 12ft, 4ft x 12ft and so on
Diameter /Gauge	10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm 12.5ga/2.5mm 13ga/2.3m
Base Optional 1	36" length x 30" width x 8"Height /914mmx762mmx203mm
Base Optional 2	36" length x 16" width x 8" Height /914mmx406mmx203mm
Base Optional 3	30" length x 18" width x 8" Height /762mm x460mm x203mm
Standard	ASTM A392-06
Steel	Galvanized Steel Construction
Finish	Corrosion-Resistant Zinc Coating
Transport Packing	Metal pallet Wrapped with Plastic
HDG zinc thickness	14 microns 100gram/SQM 28 microns 200 gram/SQM 42 microns 300 gram/SQM and 84 microns 600 gram/SQM

Chain Link Temporary Fencing detailed picture:

Chain Link Temporary Fencing production :

2.5mm Diameter Wire 3.6m Width Temporary Security Fencing With Chain Link

Chain Link Temporary Fencing Packing:

1. rubber mat at the bottom of the pallet to avoid the pallet destroyed the panel.
2. metal corners to keep the pallet more strong and wood plate on the panel pallet.
3. the metal plate under the plastic bandage to a pressure for fence panel.
4. according your request

2.5mm Diameter Wire 3.6m Width Temporary Security Fencing With Chain Link
