Easy Installation Heavy Welded Security Wire Mesh Panels Garden
Fence
Brief Introduction
V Mesh fencing systems are not known for their extreme heights,
which is why they are only appropriate for low to medium footfall
areas and why they only offer low to medium levels of security.
Typically, our V Mesh fencing is between 2.5 and 3m high, with 200
x 500mm V Mesh Apertures.
Product process:
1. Black wire→Welding→Hot dipped galvanized→Powder coated/PVC
coated
2. Black wire→Hot dipped galvanized→Welding→Powder coated/PVC
coated
3. Black wire→Welding→Electric galvanized→Powder coated/PVC coated
4. Black wire→Electric galvanized→Welding→Powder coated/PVC coated
Specification
Material: High quality low carbon steel wire
Mesh Size(common): 1.8mx3.0m; 2.0mx3.0m
Wire Diameter: 4/5mm, 5/6mm, 5/5mm
Mesh opening: 50×100mm, 50×200mm, 55×100mm, 55×200mm, 50×150mm
Post Size: (three kinds)
(1) Circular Pipe Post:
Diameter: 48mm, 60mm, 75mm, etc.
Thickness: 1.0mm, 1.5mm, 2.0mm, etc.
(2) Square Pipe Post:
Diameter: 50mm, 60mm, 80mm, etc
Thickness: 1.0mm; 1.5mm; 2.0mm, etc
(3) Peach-style Pipe Post
Surface treatment: Hot galvanized; Electro galvanized; powder
coated and PVC coated
Colors: 6005 dark green, grey, white, yellow, lawn green and red.
Same colors are used for panels and posts commonly, while different
colors can also be used to form a contrast.
| Height(mm) | Post Centres (mm) | Post Dimensions (mm) | Overall Post Lengths (mm) |
| 1525 | 3034 | 60×40 | 2100 |
| 1810 | 3034 | 60×40 | 2500 |
| 2010 | 3034 | 60×40 | 2800 |
| 2410 | 3034 | 60×40 | 3300 |
| Welded Wire Mesh Panel |
| Material | High quality low carbon steel wire Q235, Q195, S235J2 |
| Color | Dark Green,Blue,Dark,White, Red and so on |
| Surface Treatment | Hot dipped Galvanized then PVC coating Electric Galvanized then PVC coating Hot dipped Galvanized or Electric Galvanized |
Application
Road and transit ( highway, railway, road, city transit )
Science & Industry Zone ( factory, industry zone, sightseeing zone,
new pattern farm )
Private grounds ( courtyard, villa )
Public grounds ( park, zoo, train or bus station, lawn )
Commercial grounds ( corporation, hotel, supermarket )
Features
1. Reinforced Design
2. Easy Installation
3. Unobstructed Visibility
4. PermaCoat Maintenance Free Finish
5. 10 Year Limited Warranty
Our Service:
1. 15 days after receiving the deposit shipment.
2. We will choose high quality low price of the shipping company.
3. Loading the goods, we will track all the way, to ensure product
safety, quick to arrive at the designated ports.
4. Exclusive & unique solution can be provided by our well-trained
and professional engineers.
5. Special discount can be offered with large quantity.
6. We will try our best to meet your requirements and supply you
best quality of the products.
