Good visibility 358 welded mesh fencing durable commercial fencing
Brief Introduction of Good visibility 358 welded mesh fencing
358 fences are recognized as one of the most difficult to break
through the barrier, because it is difficult to climb. It is called
security fencing and high- strength fencing. 358 security fencing
panel can be bent in part to enhance the aesthetic effect.
The closeness of the horizontal wires in this Anti-climb fence also
makes for a mesh panel almost impossible to grip, thus climb, when
used as part of a fencing system, and thus the name “Anti-climb“.
The mesh apertures are finger/toe proof and are designed such as to
give excellent visibility through the mesh, both from perpendicular
and angled directions. The welded mesh panels have a non-aggressive
appearance with pleasant aesthetics, further adding to their
pre-eminence over other wire fencing panels.
Specification of Good visibility 358 welded mesh fencing
Mesh length × mesh width × wire diameter: 3" × 0.5" × 10# = 76.2mm
×12.7mm × 3.2mm.
Material: low carbon steel wire.
Tensile Strength of wire: 500-750 N/mm2.
Process: strong and durable welding.
Mesh size: 76.2mm × 12.7mm.
Fence length : 2m, 2.5m, 3.0m as standard.
Height: 1.5m, 1.8m, 2m, 2.4m, 2.7m, 3.0m, 4.0m, 5.2m.
| Panels | post |
| Fence | Panel Size | Post Size | Post Height | Total Number of Fixings |
| Height | Height/Width | Length/Width/Thickness | | Inters- 1 clamp | Corners-2 clamp |
| m | mm | mm | mm | | |
| 2.0 | 2007 x 2515 | 60x60x2.5mm | 2700 | 7 | 14 |
| 2.4 | 2400 x 2515 | 60x60x2.5mm | 3100 | 9 | 18 |
| 3.0 | 2400 x 2515 | 80x80x2.5mm | 3800 | 11 | 22 |
| 3.3 | 2997 x 2515 | 80x80x2.5mm | 4200 | 12 | 24 |
| 3.6 | 3302 x 2515 | 100x60x3mm | 4500 | 13 | 26 |
| 3.6 | 3607 x 2515 | 100x100x3mm | 4500 | 13 | 26 |
| 4.2 | 4204 x 2515 | 100x100x4mm | 5200 | 15 | 30 |
| 4.5 | 4496 x 2515 | 100x100x5mm | 5500 | 16 | 32 |
| 5.2 | 5207 x 2515 | 120x120x5mm | 6200 | 18 | 36 |
Application of Good visibility 358 welded mesh fencing
Prison security fence.
Military sites security fence.
School security fence.
Warehouse security fence.
Airport & seaport security fence.
Hospital security fence.
Factory security fence & gate.
Power station fence.
Pedestrian bridge screens.
Walkway security fence.
Animal enclosure.
Benefits of Good visibility 358 welded mesh fencing
358 Mesh Fence offering the following benefits:
Anti-climb: More small openings,no toe or finger holds.
Anti-cut: robust wire and welded joints make cutting very
difficult.
Better visibility: Flat,two-dimensional profile,easier to see
through than chain link.
Alarm: We can install electric alarm on this high security fence.
